If a bike is meant to ride any road in any condition, it needs to fit tires and wheels that will get the rider to and from their destination while handling every bump along the way. The Warakin will fit 700c x 50mm tires for minimum maintenance roads, just as easily as 650b x 50mm for forest trails, 700c x 35mm for your next gravel ride, or anything in between.
ADJUSTABLE GEOMETRY
The Tuning Chip rear dropout system allows the rider to lengthen or shorten the wheelbase by up to 20mm, raise or lower the bottom bracket by 4mm, and change the head tube angle by +/- 0.5º. For chunky gravel on remote roads, the longer wheelbase of the rear Tuning Chip position is set for stability and comfort. For a quick spin around town or the CX course, the front position makes for snappy handling and agile control. A middle position is also available, which covers the best of both worlds.
MULTI-SURFACE RIDING
If you want one bike that can join afternoon group rides, gravel races, overnighters, and daily commutes, the Warakin is for you. The progressive geometry, generous tire clearance, cargo and rack mounts, and smooth steel frame allow the Warakin to adapt to many types of riding. This bike has been a favorite here at Otso HQ where a 20-mile ride could include 10 miles of pavement, eight miles of gravel, and two miles of flowy singletrack for good measure.
CARGO & FENDERS
The Warakin will carry you away and carry whatever gear you need to get there. Triple mounts on the fork are ready for cargo cages and fork bags. The front triangle has three bottle cage mounting points, while the rear triangle has braze-ons for a rack to carry even more gear. Fender mounts can be found on the fork and seat stays to keep you dry on rainy days. And this list doesn't even include the bags that can be added to the bike that don't require mounts. The Warakin is ready to be configured to meet your cargoneeds.
Geometry
| 49cm | 52cm | 54cm | 56cm | 58cm | 60m | |
| Recommended rider height | 4'11"-5'2" | 5'2"-5'4" | 5'4"-5'8" | 5'8"-6'0" | 6'0"-6'2" | 6'2"-6'5" |
| Recommended rider inseam | 25"-29" | 28"-30" | 30"-33" | 32"-34" | 33"-35" | 34"-37" |
| Effective top tube | 510mm | 530mm | 545mm | 565mm | 580mm | 600mm |
| Nominal head tube angle | 70° | 70.5° | 71° | 71.5° | 72° | 72° |
| Tuning Chip induced head/seat tube angle change | ±0.2° | ±0.2° | ±0.2° | ±0.2° | ±0.2° | ±0.2° |
| Head tube length | 87mm | 95mm | 115mm | 140mm | 165mm | 185mm |
| Nominal seat tube angle | 75° | 74.5° | 74° | 73° | 72.5° | 72° |
| Seat tube length | 400mm | 505mm | 530mm | 550mm | 570mm | 590mm |
| Bottom bracket drop | 58-62mm | 68-72mm | 68-72mm | 68-72mm | 68-72mm | 68-72mm |
| Chainstay length | 410-430mm | 420-440mm | 420-440mm | 420-440mm | 420-440mm | 420-440mm |
| Wheelbase | 1000-1020mm | 1017-1037mm | 1023-1043mm | 1028-1048mm | 1032-1052mm | 1046-1066mm |
| Trail | 70mm | 71mm | 70mm | 67.5mm | 65mm | 65mm |
| Fork offset | 47mm | 47mm | 47mm | 47mm | 47mm | 47mm |
| Rigid fork axle to crown length | 420mm | 420mm | 420mm | 420mm | 420mm | 420mm |
| Stack | 532mm | 549mm | 570mm | 596mm | 622mm | 641mm |
| Reach | 368mm | 378mm | 381mm | 383mm | 384mm | 392mm |
| Standover | 677mm | 760mm | 780mm | 800mm | 820mm | 840 mm |
